PARTS LIST continued

Page 4 SET 5267

Item No. Function/Rating Mfr. Part No. Notes

R311 (2) 10K 1% 1/4W 268385 -

R312 18K 1% 1/4W 268386 -

R404 4700 5% 7W 268390 -

# R431 1 5% 2W Fusible 266932 -

# R432 (1) 5600 5% 1/6W 268379 -

# R432 (2) 6800 5% 1/6W 266372 -

# R433 1 5% 2W Fusible 266932 -

# R453 1000 5% 1/6W 266255 -

# R460 (1) 150K 5% 1/2W 270383 -

# R461 (1) 3.9 5% 2W Fusible 270925 -

# R461 (2) 1.8 5% 2W Fusible 268430 -

# R501 (1) 560 5% 1/6W 268377 -

# R502, 03 (1) 680 5% 1/6W 266272 -

# R505 (1) 560 5% 1/6W 268377 -

# R506 (1) 680 5% 1/6W 266272 -

# R508, 09 (1) 680 5% 1/6W 266272 -

# R510 (1) 560 5% 1/6W 268377 -

# R516, 17, 18 4700 5% 1/6W 266282 -

# R801 1M 20% 1/2W 266940 -

R820 Fuse 268410 5Amp, 250VAC

R821, 23 Fuse 268411 3Amp, 250VAC

R827 (1) 10 5% 2W 179284 -

R827 (2) 4700 5% 5W 268413 -

R834A 6800 1% 1/4W 176634 -

R834B 390 1% 1/4W 266595 -

R835 120K 1% 1/2W 268414 -

# R840 8.2M 1W 266941 -

# RL01 Relay 268417 Degaussing

# RT801 (1) PTC 270926 -

# RT801 (2) PTC 268418 -

S001A Switch 266289 TV/AV

S002A Switch 266289 Menu

S003A Switch 266289 Volume -

S004A Switch 266289 Volume +

S005A Switch 266289 Channel -

S006A Switch 266289 Channel +

S008 Switch 266289 Power

# S501 Socket 266290 CRT

# T401 Horizontal Drive 266291 -

# T402 (3) Horizontal Output 268419 -

# T801, 02 Line Filter 268420 -

# T803 Power 268421 -

TU101 Tuner 270388 TEDH9-251A

# V801 CRT - A68ELA021X004

VR802 (1) 330 B+ 270389 -

VR802 (2) 2000 B+ 268422 -

W601, 02 (1) Speaker 268472 60mm X 160mm, 16 Ohms, 8W

W601, 02 (2) Speaker 268488 60mm X 160mm, 16 Ohms, 12W

X001 Crystal 266315 8MHz

X201 Trap 266318 4.5MHz

X202 Filter 266317 4.5MHz

X1001 Crystal 268423 18.432MHz

Z101 Filter 266319 SAW

PC Board (1) 270966 Side AV

PC Board (1) 270963 Comb Filter

PC Board (1) 268432 CRT

PC Board (2) 268446 CRT

PC Board (1) 270968 Control

Spacer 267049 Yoke Positioning (3 Used)

Transmitter 270372 Remote

# For SAFETY use only equivalent replacement part.

(1) Used in model 24F512T.

(2) Used in model 24V511T.

(3) Screen and focus controls are part of T402.

Important Parts Information

n Parts not listed in the parts list are commonly available at your local electronics parts retailer.

n The parts listed here are those not usually available from a well-stocked supply cabinet or bin.

n On the parts lists, safety items are marked with a # to remind you that only exact replacements are recommended for

these items.

n When ordering parts, state the model number, part number, and description.

Obtaining Parts

Many of these parts are available from your local Sams authorized distributor or the manufacturer of the equipment. Call

Sams for the name of your nearest distributor:

800-428-7267
