10
5. Connect the telephone line cords:
Connections and Setup
3
4
5
6
4. Attaching the Desktop Pedestal:
A. Turn the phone over so that the bottom of the base is facing up
and the end with data port and line jacks is pointing away from
you.
B
. Turn the desktop pedestal so that the side with four rectangle
rubber feet is facing you.
C. Insert the tabs on the pedestal into the two lower slots on the
bottom of the base, then push the pedestal downward until the
tabs on the top of the pedestal snap (lock) into place.
