26
Using the Monitors
Wide Frame Indicator
SP
Tape Speed Indicator
40X
Zoom Ratio
Back Lighting Indicator
REC/PAUSE
Record/Pause Indicators
Active Tape Indicator
White Balance Adjustment
Snapshot Indicator
+
2
—
Exposure Adjustment Icon
+
2
—
Iris Lock Indicator
Recording Mode Indicators (
A
or
M
)
Appears when the camcorder is in 16x9 mode
(wide screen).
Display of the set recording speed (either
Standard Play [SP] or Long Play [LP]).
Displays the approximate zoom ratio during
zooming.
•
appears when GAIN UP is set to
AUTO and the shutter speed is
automatically adjusted.
•
W
T
is the zoom lever indicator.
Appears when back lighting compensation is
turned on.
• REC appears during recording.
• PAUSE appears during Record-Standby.
Appears when a tape is running.
Appears when white balance is adjusted.
Appears when a snapshot is being taken.
Appears when the exposure is adjusted.
Appears when the iris is locked.
