DBS Signal Splitting
1. Hook up the DBS Receiver as outlined in the Receiver Owners Manual.
2. Using a 2 Way Signal Splitter (RCA Model D800)/4 Way Signal Splitter
(RCA Model D810) connect the splitter “Input” to the DBS Receiver
“Out to TV”. This will require a small length of coaxial cable.
3. Connect one output of the splitter to the original TV and connect the
other output to the second TV via coaxial cable.
REMOTE CONTROL
REMOTE CONTROL SIGNAL
SENDER EXTENSION
REMOTE CONTROL SIGNAL
SENDER BASE UNIT
COAXIAL CABLE
DBS RECEIVER
