Chapter 1: Connections and Setup
Chapter 18
Front Panel - J22H760
1. VOL- / VOL+
Adjusts sound level and menu settings.
2. CH / CH
Select a channel.
3. SOURCE
Selects the TV, AV1, AV2, YPbPr, VGA, HDMI or USB mode.
4. MENU
Display on screen menus.
5. POWER
Switches the set on or off.
6. Power Indicator
Illuminates to bright blue when the TV is on. When the TV is powered off, this LED is also off.
Remote control sensor
Accepts the IR signal of remote controller.
