Take the neck. Please align the screw holes of the neck and the
TV, and then insert the 6 machine screws into the 6 holes on
the neck and tighten them.
TV LED46A55R120Q is packaged with the TV stand separated from the cabinet. To setup the TV table stand, please carry out
the installation according to the instructions below.
The panel can be scratched easily, so please:
1. Choose an absolutely flat surface to place the TV on.
2. Use soft cloth or cushion to face the TV panel.
Do not put TV on the table directly.
Always unplug the AC cord first when installing/removing
the stand.
Step One
Place the TV faced down on a soft cloth or cushion to prevent the
panel from being damaged.
Step Three
Take the base. Please align six holes of the base and six
screwholes of the neck, insert the base to the neck, and then
insert the 6 tapping screws and tighten them.
Step Two
RS01TM410H
Pedestal Screws Quantity Part #
6pcsM4 x 10mm
TV Stand Installation
9
The bottom view of the TV
( Front cabinet faces down)
RS01TB410H
Pedestal Screws Quantity Part #
6pcsM4 x 10mm
To Next Page
