“-7
❑ SEALTHE OPEMH6S
Seal any openings in the wall behind the range
and in the floor under the range when hookups
are completed.
ElUm’mu?Pulol’S
(for models equipped with standing pilots)
The range should be installed in its permanent
position before any pilots are lit or adjusted.
Ligbtthosurkti-
CAUTION Make sure the surfiice burner
control knobs are in the OFF position before
attempting to light the pilots.
1. Raisethe cooktop.
2. Light both pilots with a match.
3. To avoid pilot outage, use caution when
closing cooktop after lighting pilots.
NOTE: Do not leave standing pilot lit in a newly
constructed or remodeled home or apartment
that willbe unoccupied for more than a month.
Each pilot flame was adjusted at the factory to be
approximately 5/16” tall. Atinge ofyellow
appearing at the upper tip is normal. Ifyou find
pilot adjustment is necessary, seethe following
instructions.
34
Mid the Surfoa Bunm’ FiIots Bfnecessary
10 Raise the cooktop.
2. Locate the pilot
adjustment screw. It can
be accessed through the
small hole near the center
ofthe manifold panel.
3. To adjus$ use a blad&ype screwdriver with
a shaft diameter of less than 3/16”. Turn pilot
adjustment screw until pilot is 5/16” high. Do
not reduce the flame to less than 5/16” or pilot
outage may occur. A pilot flame burning higher
than recommended may generate soot (carbon
black) on the bottom of your cooktop.
Lighttheoven Pilot
CAUTION: Make sure the OVEN CONTROL
1
knob is in the OFF position before attempting to
light the pilot
1. Remove the broiler drawer by sliding the
drawer all the way out and then lifting slightly to
remove it fi-omit’stracks.
2. Locate the pilot at the
back of the broiler
compartment The pilot
is attached to the left
side of the oven burner.
3. Light the pilot with a
match. No adjustments are
required for natural gas.
For U? gas, see How to
Convert the Range for
Use with LP Gas or
Natural Gas.
——
————..—...———-----
