Stand-By Filet Flame
Heater Pilot Flame
4. Turn the OVEN CONTROLknob to a setting
above 200°I! The pilot flame willincrease in size
and impinge on the temperatureresponse element
The oven burner willlight in 3090 seconds.
The oven burner will operate until the set
temperature is reached. The oven burner will
continue to cycle on and off as necessary to
maintain the oven at the temperature indicated
by the OVEN CONTROLknob.
❑lCHKK16UIT9QUOFSURFACEBURNERS
Su8iuo Bamwr Ignition
Operation of all cooktop and oven burners
should be checked after the pilots have been
lighted (on some models) and range and gas
supplylines have been carefullychecked forleaks.
‘Standing Pilot Models
Select atop burner knob and simultaneouslypush
in and turn to HI position. The burner should
light within a few seconds. Try each burner in
succession until all burners have been checked.
Electric
IgnitionModels
Select atop burner knob and simultaneously
push in and tqm @LITE position. Youwillhear a
Snapp”
Y
sound indicatin proper operation of
~
the spar module. Once e air has been purged
from the supply lines, burners should light within
4 seconds. Afterburner lights, rotate knob out of
the LITE position. Try each burner in succession
until all burners have been checked.
*rhf
Of F&mos
The combustion quality of burner flames needs
to be determined visually.
(A) Yellow flames-
Callfor service
(B) Yellow
tips on
outer cones-
Normalfor LP gas
(Q M blue flames-
Normal for natural gas
Ifburner flames look like (A),call
for service.
Normal burner flames should look like (B) or
(C), depending on the type of gas you use.
With IF gas, some yellow tipping on outer
cones is normal.
❑=cK lGM1liOWOF OVEN BURNER
Youroven is designed to operate quietly and
%
automati .To operate the oven,turn the OVEN
CONTROL ob to a setting above 200°1?After
30-90seconds, the oven burner will ignite and
bum until the set temperature is reached. The
oven burner willcontinue to cycle on and off as
7
nec
to maintain the oven at the temperature
indicate by the OVEN CONTROLknob.
Electric ignition models require electrical
power to operate. The oven cannot be lit during a
power outage. Gas will not flowunless the glow
bar is hot
Ifthe oven is in use when a power outage occurs,
the burner will shut off and cannot be relit until
power is restored.
(com”nued next page)
35
..
