RCA LGB146

nowTo CONVERTA SEMED BURNER RM16E
FOR USEWITH 1P GAS OR HATURAL (MS
This range
leaves the f%ctoryset for use with natural
gas. If you convert to LPgas, keep these instructions
and orifices in case you want to convert back to
natural gas.
The conversion should be done by a qualified
technician or installer.
Tools REQu9REh
Adjustable wrench
1/2” openad wrench
Flat blade screwdriver (small)
Nut drivers or wrenches: 9/32” or 7mm
❑ PREPARERAH6E FOR CONVERSION
(1) T- off gas supply at the wall.
(2) T- off the electrkxd power to the range.
Ifrangehas not yet been connected to gas
SUpply,
or if flexible connection was made, range maybe
pulled out from the wall to make conversion easier.
❑ =WM THE PRESSUREREGULATOR
W~& Do not remove tie pressure
regulator fi-omthe range.
1. Remove the broiler drawer and locate the
pressure regulator at the rear of the range.
J
Remove Screws
\ ,~
Access Cover
+p–mh
On some models, you may have to remove an
access cover also.
2. Followthe directions in box ~ or
❑ that
match your regulator type.
hi
Mlf k Ibk Regulutm
1. Use an adjustable wrench to remove the
nut ii=omthe pressure regulator.
NAT W
2. Apply sideward iinger pressure to remove
the plastic pin fi=omthe nut
HINT’:To remove the pin, place the nut on
a flat surface and press the pin sideways with
your fingers.
3. Push down on the disc edges to replace the
pin in the nut
NAT
w
LP
$
.
I
I
@
f
4. Reinsert the assembly into the regulator.
1.
Unscrew the plastic-protected hex-nut *=mbly
cap tiom the regulator.
20 Carefully pry the protective plastic cap off
the threaded metal cap. Gently pull the plastic
washer off the threads on the other side ofthe
metal cap.
3. Push the plastic cap onto the end of the metal
cap displaying the type of gas you are converting
to. Press the attached plastic washer onto the
threads on the other side ofthe metal cap.
4. Screw the hex-nut cap back into the regulator.
~
Do not overtighten.
