Installation
0
1
Attach the white plug on one end of the included
0
2 Attach the yellow video plug on one end of the
audio/video cable to the AUDIO IN jack on the included audio/video cable to the VIDEO IN jack
TV or VCR and the other white plug to the on the TV or VCR and the other yellow plug to
white audio jack located under the door on the
the yellow video jack located under the door on
side of the camcorder.
the side of the camcorder.
Note:
If your TV or VCR has stereo
AUDIO
jacks,
attach the
AUDIO
plug to the one labeled MONO. If
one
is not labeled MONO, you may need a Y-adapter
to
hear sound from both channels.
Playback Operation and How to Copy Tapes on the VCR
1.
A. Camcorder connected directly to TV monitor:
Turn on the TV and tune it to the video input
channel.
B. Camcorder connected to VCR that is already
connected to TV: Turn on VCR and place it in
the “line” or “camera mode”. (If your VCR
does not have a “line” or “camera mode”,
consult the VCR owner’s manual.) Operate the
TV as you normally do to see the signal
coming from the VCR.
2. Attach a power supply, and press and hold the
small button on the camcorder’s POWER switch
4. Press PLAY to begin playback
-During playback, use the playback
features described
011
pugc~
33.
5.
To copy what the camcorder is playing,
place a blank cassette in the VCR, and
press the VCR’s RECORD button.
Caution: The unauthorized
recording of television programs and
other recorded material may infringe
the rights of others.
while you place it in PLAY.
3. Insert the cassette you want to play back.
6. Press STOP when you are finished.
Viewing What the Camcorder is Seeing (or Recording)
1. A. Camcorder connected directly to TV: Turn on while you place it in CAM. Place ON/POWER
the TV, and tune it to the video input channel.
SAVE
in ON, and insert the cassette you want to
B. Camcorder connected to VCR that is already
connected to TV: Turn on VCR and place it in
the “line” or “camera mode”. (If your VCR
does not have a “line” or “camera mode”,
consult the VCR owner’s manual.) Operate the
TV as you normally do to see the signal
coming from the VCR.
2. Attach a power supply and press and hold the
small button on the camcorder’s POWER switch
record on.
Note:
When the camcorder is used as a camera, turn the
TV’s volume down to
prevent
a high-pitched squeal
caused by feedback.
3. Press the camcorder’s thumb trigger
(START/STOP on remote) to begin recording.
You can watch what the camcorder is seeing (or
recording) on the TV screen.
35
