RCA rd1060 - 64 MB Kazoo Digital Audio Player

EN
Display
POPBASS
FLAT
ROCK
JAZZ
P
k
TRACK
ALL
DSP modes
Total number of
track / Current track
number during
playback
Volume level bar
Encoded bit rate
Repeat mode Random mode
Total playing time on card / Elapsed time during playback
Key locked
Battery level indicator
Multimedia card
inserted
Program
mode
Connection cable
connected
5
General Controls
PHONES
MODE
DSP
MEMORY
CARD
VOLUME
OFF- LOCK
S
T
O
P
L
A
S
T
N
E
X
T
P
L
A
Y
EJECT
1
2
3
5
9
10
12
14
13
11
8
6
7
4
1. Display
2. STOP - Stop playback and turn unit
off .
3. LAST - Skip back to last track. Press
and hold to search backward within
the same track.
4. NEXT - Skip to next track. Press and
hold to search forward within saved
tracks.
5. PLAY - Turn unit on, start playback
and pause.
6. DSP - Select among DSP modes.
(Flat, Bass,Pop, Rock,Jazz)
7. MODE - Select between repeat,
program and random playback modes.
8. LOCK - To lock keys to avoid
accidental key activation.
9. MEMORY CARD - Slot for inserting
MutliMediaCard.
10. VOLUME - Adjust sound volume.
11. PHONES - Insert headphones.
12. USB - Connect USB cable.
13. Battery compartment door
14. EJECT - Slide to eject MutliMedia
Card.
6
