STANDARD INSTALLATION

(1) Secure the wall brackets with the bolts(not provided as parts of the product, must

purchase separately) on the wall.Match the height of the bracket that is mounted on

the wall. The wall bracket is of nomal dimension. Please see the position of the wall

brackets bolts as follow picture. The actual dimension of the wall brackts bolt should

according to the products.

(2) Remove the table stand of the TV when install the TV on a wall as follow:

(3) For proper ventilation, allow a clearance of 10” on each side from the wall.

The wall brackets bolt position

b. Wall Mount: Horizontal installation

75mm

Four Mounting

Holes

Size:M4 Screws

10inches
