Front/Back panel diagram
8
14/15. VIDEO/R/L :1/2 external AV
signal input and relevant right/left
sound channel.
S-VIDEO: Color and brightness
difference components input.
VGA/AUDIO: VGA audio input.
ANT 75 ohm: Connect the antenna to
the antenna input.
HDMI Input: Digital signal input from
HDMI video connector
YPbPr:Color difference
components input and relevant
video input
AV Output
16. POWER(DC IN) Connect to Mains
Adapter
1415
9
VIDEORL
VIDEORL
OUTPUT
INPUT
Y
P
b
P
r
VIDEORL
S-VIDEO
HDMI
11 1
22 2
4A
16
(3.5mm)
