22
External Connection
Connecting Digital Audio System
The rear panel jacks on your TV make it easy to connect a Digital Audio System to your TV.
TV Rear Panel
Digital Audio System
(Black)
5.1 CH audio is possible when the TV is connected to an external device supporting 5.1 CH.
Connect a optical cable between the optical jacks on the TV and the Digital Audio Input jacks on the Digital
Audio System. When a Digital Audio System is connected to the a coaxial terminal:
Decrease the gain (volume) of the TV, and adjust the volume level with the volume
control.
Digital Audio System's
AV IN
SPDIFUSB1
5V 500mA
RF
HDMI1(ARC)
HDMI2HDMI3
USB2
5V 500mA
Optical Cable (Not supplied)
To Next Page
