8
ENGLISH
EXAMPLES
— SUPERMARKET
A BM 3022 paging microphone is placed on every cash desk.
All paging microphones are linked in series (‘daisy-chain’) and interlocked
one another.
Dip-switch 2 and 3 settings on all paging microphones:
- dip-switch no.2: OFF (no priority)
- dip-switch no.3: I/Lock (interlocking mode)
As option, it is possible to add a BM 3022 paging microphone having priority
(dip-switch no.2 set to ON) for the head office.
— CONFERENCE HALL
One BM 3022 for every delegate and one having priority for the chairman.
All paging microphones are linked in series (‘daisy-chain’) and operating in
mixing mode (but the chairman’s one with priority).
Dip-switch 2 and 3 settings:
- dip-switch no.2 (delegates’ microphones): OFF (no priority)
- dip-switch no.2 (chairman’s microphone): ON (with priority)
- dip-switch no.3: Mix (mixing mode)
PRIORITY: ON
