RCF BM3001 - Specifications

11
ENGLISH
SPECIFICATIONS
Type Desktop paging microphone with electret capsule
Polar pattern Cardioid
Sensitivity -65 dB +/- 3 dB (0 dB = 1 μbar @ 1 khz )
Minimum load impedance 470 Ω
Nominal output voltage 100 mV rms (@ 3,3 kΩ); max 1 V rms
Frequency response 50÷18000 Hz
Power supply Phantom 18 ÷ 48 V dc
Consumption 2.8 mA
Dimensions 100 x 159 x 48 mm (without gooseneck)
Weight 0.7 kg
Included accessories 5 m CAT5 FTP cable
BM3001 BM3001
Brown
Brown/ White
Green
Blue/ White
Blue
Green/ White
Orange
Orange/White
1 2 3 4 5 6 7 8
Green
Blue
Orange
Orange/White
gnd
+
–
Priority command
output (to gnd)
Audio signal
Example of connection to RCF ES 3160 mixer-amplifier
Example of cable (not included) for connections to generic mixers
(with ‘phantom’ p.s.).
