11 | P ag e
GAS BARBECUE SPECIFICATIONS
BURNER INPUT RATING
Natural Gas Connection:
Appliance pressure 4” W.C.
Inlet pressure 5” – 14” W.C.
Check with your local gas utility company or with local codes before installing gas lines.
Installation in Canada must be in accordance with the standard CAN/CGA- B149.2
A licensed contractor or local gas company representative must perform all gas
connections
L
P Gas Connection
Appliance pressure 10” W.C.
Inlet pressure 11” – 14” W.C.
Purchase a standard 20 LB. LP tank with QCC – 1 fitting, and an
approved hose and low pressure regulator like the RCS: RONHK. (Available
From Your RCS Dealer) Assemble pipe/hose assembly as shown (not
included).
Grill Model Main Burners
Rear Burners
Total BTU’s
RJC26A 12,000
-
36,000
RJC32A / RJC32AL
12,000
12,000
60,000
RJC40A / RJC40AL
12,000
12,000
72,000
RON30A 15,000
12,500
57,500
RON38A 15,000
12,500
72,500
RON42A 15,000
12,500
72,500
The RONHK hose kit is shown here.
