If adding a side burner to your connection:
Electrical
Electrical outlet for Rotisserie motor must be installed to the left side of the grill.
The outdoor cooking gas appliance, when installed, must be electrically grounded in
accordance with local codes or, in the absence of local codes, with the National
Electrical Code, ANSI/NFPA 70, or the Canadian Electrical Code, CSA C22.1.
Keep any electrical supply cord and fuel supply hose away from any heated surface.
HALOGEN LIGHT: The RJC32AL, RJC40AL, RON30A, RON38A & RON42A are
provided with a low-wattage transformer. Connect 115V power to the grill.
USE the transformer provided! Replacement light bulb is 12v, 5 watts.
17 | P ag e
On the RON30a, RON38a
and RON42a, this plug is
specially used for
connecting the optional
RDB1EL side burner.
