Page 2 of 2
Step 3
Step 4
Attach center rail (02) to slat kit (01).
Using Allen screw (A), tighten with the Allen
wrench (C).
Repeat for section 2.
Lay the slat kit (01) onto the bed.
Screw slat kit (01) to side rail, using wood screw (B).
Tighten with Phillips head screwdriver.
B
A
A
01
01
B
1 1/4” Wood screw
SECTION 1
SECTION 2
Phillips head
screwdriver
Customer supplied
Be sure the space between slats is even.
If using a Trundle Bed attach center rail off center
as shown. Repeat for section 2.
SECTION 1
Be sure to align slat kit evenly with both
ends of ledger strip.
02
B
A
A
A
A
1 1/2” Allen screw
C
Allen wrench
SLAT KIT FULL BED
Adult assembly
Adult assembly
