Gas Rate Chart
Model LPG Natural Gas
650 36 MJ/h 38 MJ/h
700 34 MJ/h 39 MJ/h
800 42 MJ/h 40 MJ/h
900 50 MJ/h 40 MJ/h
1000 51 MJ/h 47 MJ/h
1200 65 MJ/h 53 MJ/h
1500 65 MJ/h 51 MJ/h
A suitable gas supply needs to be provided at the right hand rear corner of the timber frame cavity. The pipe sizing
should be calculated to supply gas to suit the megajoule rating of the fire. See rating chart. The gas supply should
be reduced down to 10mm copper pipe at the fireplace location and left with a coil of approx 1 metre to feed into
the firebox.
Gas supply
An electrical supply will required for fires fitted with the optional Fan Set or Electric On/O. This should be by
means of a wall switch provided by an electrician and located near the fireplace. Not inside the fireplace cavity.
See installation drawing for preferred location of switch.
Electrical supply
Recessed rebox installation
Standard wall linings are not suitable for recessed installation
Please contact Real Fires for advice prior to installation
When installed into timber framing the Real Fire must be installed with an insulation kit. This must be ordered with
the fire and fitted in the factory by Real Fires. The insulation kit allows the firebox to be installed with minimal
timber clearances: 10mm clearance on sides of firebox and 25mm clearance from rear and top of firebox
The timber clearance from the twin wall flue is also 25mm. There is no requirement for any additional fireproof
materials within the fireplace cavity providing minimum clearances are allowed.
Insulation Kit & Timber Clearance
