Gas Rate Chart
Model LPG Natural Gas
650 36 MJ/h 38 MJ/h
700 34 MJ/h 39 MJ/h
800 42 MJ/h 40 MJ/h
900 50 MJ/h 40 MJ/h
1000 51 MJ/h 47 MJ/h
1200 65 MJ/h 53 MJ/h
Cowl Requirements
600mm Fire 150mm Cowl 900mm Fire 200mm Cowl
650mm Fire 150mm Cowl 1000mm Fire 200mm Cowl
700mm Fire 150mm Cowl 1200mm Fire 250mm Cowl
800mm Fire 200mm Cowl
A suitable gas supply needs to be provided at the right hand rear corner of the fireplace cavity. The pipe sizing
should be calculated to supply gas to suit the megajoule rating of the fire. See rating chart. The gas supply should
be reduced down to 10mm copper pipe at the fireplace location and left with a 10mm coil of approx 1 metre to
feed into the firebox.
Gas supply
An electrical supply will required for fires fitted with the optional Fan Set or Electric On/O. This should be by
means of a wall switch provided by an electrician and located near the fireplace. Not inside the fireplace cavity.
Electrical supply
Performance of the fire will be improved if the fireplace cavity is lined with a suitable insulating fire rated product
such as Rockwool.
Recommendation
