Fit the Stainless Steel or Black trim to the firebox. The trim brackets are designed to hang over the flange on the
front of the firebox. The flange has provision to be moved slightly in or out to allow the bracket to fit. The flange
on each side of the firebox has raised square near the base of the fire. The Velcro pad is fixed to this by removing
the backing from one side one side of the pad and pushing firmly in place. Then remove the backing from the
other side. Repeat on opposite side. Hang trim on brackets and check for level then push firmly onto Velcro pad.
Fitting Trim to rebox
Once the installation is complete, instruct the user on the operation of the fire and complete commissioning
details in the Real Fires user manual.
Instruct User
ALL INSTALLATIONS MUST BE CERTIFIED
If a fan has been selected with the fire, it will already be fitted in the firebox at the factory. It is controlled by a wall
switch, which should be fitted by an electrician. There is no switching on the fire and the wall switch is not suppled
by Real Fires.
Optional Fan
Check burner gas pressure from the test point on the burner supply pipe on the Natural Gas Model and on the
injector elbow on the L.P.G. model.
Burner Gas pressure
Adjust the pressure at the regulator if required.
See appliance data badge for pressure settings
Check the re is operating correctly and test for spillage of combustion products
