RTL8188CEB8
Combo mini-Card User Manual
Product specifications
2.3. Mini PCI Express Pin Assignment
Table 1. Mini PCI Express Pin Assignment
PIN#ʳPin Nameʳ
ʳʳ
PIN# Pin Nameʳ
ʳʳ
1ʳWAKE#ʳYESʳ2ʳ3.3VauxʳYESʳ
3ʳCOEX1ʳYESʳ4ʳGNDʳYESʳ
5ʳCOEX2ʳYESʳ6ʳ+1.5V (Option)ʳYESʳ
7ʳCLKREQ#ʳYESʳ8ʳUIM_PWRʳNCʳ
9ʳGNDʳYESʳ10ʳ
UIM_DATA
NCʳ
11ʳREFCLK-ʳYESʳ12ʳ
UIM_CLK
NCʳ
13ʳREFCLK+ʳYESʳ14ʳ
UIM_RESET
NCʳ
15ʳGNDʳYESʳ16ʳ
UIM_VPP
NCʳ
17ʳRESERVEDʳNCʳ18ʳ GNDʳYESʳ
19ʳBT_DISABLE# (Option)ʳYESʳ20ʳ W_DISABLE#ʳYESʳ
21ʳGNDʳYESʳ22ʳ PERST#ʳYESʳ
23ʳPERn0ʳYESʳ24ʳ +3.3VauxʳNCʳ
25ʳPERp0ʳYESʳ26ʳ GNDʳYESʳ
27ʳGNDʳYESʳ28ʳ +1.5V (Option)ʳYESʳ
29ʳGNDʳYESʳ30ʳ SMB_CLKʳNCʳ
31ʳPETn0ʳYESʳ32ʳ SMB_DATAʳNCʳ
33ʳPETp0ʳYESʳ34ʳ GNDʳYESʳ
35ʳGND YESʳ36ʳ USB_D-ʳYESʳ
37ʳGND YESʳ38ʳ USB_D+ʳYESʳ
39ʳ+3.3Vaux NCʳ40ʳGNDʳNCʳ
41ʳ+3.3Vaux NC 42ʳ LED_WWAN#ʳNCʳ
43ʳGND YES 44ʳ LED_WLAN#ʳYESʳ
45ʳRESERVEDʳNCʳ46ʳ LED_WPAN#ʳYESʳ
47ʳRESERVEDʳNCʳ48ʳ +1.5V (Option)ʳYESʳ
49ʳRESERVEDʳNCʳ50ʳ GNDʳYESʳ
51ʳBT_DISABLE# (Option)ʳYESʳ52ʳ +3.3VauxʳYESʳ
4 Rev.1.0
