RTL8188CEB8
Combo mini-Card User Manual
802.11g:
54, 48, 36, 24, 18, 12, 9, 6 Mbps
802.11n:
MCS 0 to 7 for HT20MHz;
MCS 0 to 7 for HT40MHz
BT:
1/2/3 Mbps
Media Access Control
WiFi:
CSMA/CA with ACK
WiFi + BT:
AFH, Time Division
Modulation Techniques
802.11b:
CCK, DQPSK, DBPSK
802.11g:
64 QAM, 16 QAM, QPSK, BPSK
802.11n:
BPSK, QPSK, 16-QAM, 64-QAM
BT:
GFSK, "/4 DQPSK, 8DPSK
Network Architecture
WiFi:
Ad-hoc mode (Peer-to-Peer )
Infrastructure mode
Operating Channel
WiFi 2.4GHz:
11: (Ch. 1-11) – United States
13: (Ch. 1-13) – Europe
13: (Ch. 1-14) – Japan
BT 2.4GHz:
Ch. 0 ~78
Frequency Range
2.400GHz ~ 2.4835 GHz
Security
WiFi :
WPA, WPA-PSK, WPA2, WPA2-PSK, WEP 64bit & 128bit, IEEE
802.11x, IEEE 802.11i
BT:
Simple Paring
Operating Voltage
3.3 V ±9% I/O supply voltage
6 Rev.1.0
