RTL8762D Evaluation Board User Manual
Copyright 2021 Realtek Semiconductor Corporation. All Rights Reserved.
6
1.
RTL8762D Evaluation Board Introduction
1.1
RTL8762D EVB introduction
This document introduces usage of 8762D Bluetooth
®
Evaluation Board (EVB) Hardware. 8762D EVB provides
hardware environment for customer to develop their own application, which includes:
1. Voltage converter.
2. 6-axis motion sensor.
3. 4 LEDs and 6 keys.
4. Button battery and Li-ion battery holder.
5. USB to UART converter (FT232RL).
1.2
Evaluation Board Interface
1.2.1
Interface Description
Distribution of EVB block and interface is shown in Figure 1-1 and Figure 1-2.
Figure 1-1 EVB Interface Block Diagram
