Realtek RTL8762D - Page 4

5.1
• BT5/Cortex M4F 40MHz; 160KB RAM
• Voice ADC for voice search; IR
transceiver
• Tx Power up to +7.5dBm
• Low Power; ADCx8; EQ Bandx5
• I2C/SPI/UART/I2S/PWMx8
• 240x240 I8080 I/F supports
• Support Scatternet/Routing based on BT
SIG
• Support BLE HomeKit / Amazon BLE
Mesh / Amazon Gadget
• BT5.1
• Cortex-M4F 90MHz, 192KB SRAM for
sensor fusion
• SPIC(XiP) for flash, max 32MB (45MHz)
• SPIC(XiP) for PSRAM, max 8MB (45MHz)
• SPIC for AMOLED (45MHz)
• I8080 for TFT/AMOLED (20MHz)
• SPI for TFT (45MHz)
• Supports AMOLED 454x454
• Ultra low power consumption
RTL8762CRTL8762D
HoneyBEE
BLE SoC
2
• BLE5.2
• Cortex M0+ 40MHz, 1MB Flash,
104KB SRAM
• Capacitive touch sensor
• RF TX 4.75mA (0dBm), RX 3.5mA
• QFN32/40/48
• ES: 2021/Q2, MP: 2021/Q4
5.2
RTL8762E
5
NEW
Find More
Copyright 2021 Realtek Semiconductor Corporation. All Rights Reserved.
II
Realtek Bluetooth Solutions
Wristband
Realtek for
2021 Tech Day
