Realtree UT400-RT - Hardware Sizing Guide; Bolts; Nuts & Washers

M6 x 60 Bolt
M6x30 Bolt
M6x20 Bolt
M8x15 Bolt
M8x25-
M10x16 Hex
Button Bolt
M10x15
Shoulder Bolt
M10x15
Hex Bolt
M10x25 Bolt
M6 Flange Nut
M8 Flange Nut
M10 Flange
Lock Nut
M6 Acorn Nut
M10 Acorn Nut
Curved Washer
(Large)
Rubber Gromet
M10 Lock Washer
M6 Lock Washer
M8 Shaft Washer
M8 Cap Post Nut
POWERSPORTS
UT400 Hardware Sizing Guide
M6
M8
M10
0 10 20 30 40 50 60 70 80 90 100 110 120
*For use on Coleman Powersports models including Coleman 400, Realtree 400, UT400, UT400-RT, Craftsman 400.
Included hardware is subject to change at any time. ©2021 Coleman Powersports 9J13R21
M6
M8
M10
BOLTS
NUTS & WASHERS
NOTE: Images are to scale
