12mm - Socket Wrench
4m - Allen Head Wrench
NOTE: Before installing Steering Wheel,
ensure the front tires are straight and in line
with the rear tires.
1. Slide steering wheel onto steering shaft,
ensuring steering wheel slides over groves on
steering shaft with holes facing up. Align steer-
ing according to pictures with large open area
facing up.
2. Fasten using 12mm lock nut.
3. Insert and tighten top and bottom bolts
to steering assembly.
4. Place black center cap over center of
steering wheel. Place clamp ring over center
cap, align fastener holes with holes on steering
wheel.
5. Fasten using 6 - 4mm allen bolts
provided in the steering wheel pack.
6. Tighten until snug.
Steering Column
12mm
Lock Nut
Center Cap
Clamp Ring
6mm Hex
Head Bolts
To Next Page
