SP076 & SP077. Acve Swing Add-ons. Instrucon Manual
You will need/supplied...
mm
0 10 20 30 40 50 60 70 80 90 100 110 120 130
5mm - 5.5mm Drill Bit
10mm Drill Bit
PZ2 Screwdriver
PZ2 Bit
Powered Drill
Tape Measure13mm Spanner 13mm Socket
SP076/SP077 Contents...
55mm Wood Screw x4
M8x65 Hex Bolt x4
M8x90 Hex Bolt x2
Washer x14
Nut x7 Cap x18
PR0361 x2/x4
RB068 x1
Wood Proles:
WD02-1060 (120x20) x 1060mm x1
WD03-1980 (69x44) x 1980mm x2
WD04-1100 (69x69) x 1100mm x1
WD04-1900 (69x69) x 1900mm x1
W1
W2
W3
W3
SP077 - DOUBLE SWING
SP076 - SINGLE SWING
WD2053 (120x20) x 0290mm x2 W4
PR0355 x1
85°
PR0356 x1
95°
M8x150 Hex Bolt x1
35mm Wood Screw x6
