SPECIAL INSTALLATIONS
WATER PLATFORMS
The REC solar panels covered by this manual may be installed on water platform-type mounting systems (note that the certification test-
ing of solar panels does not include testing on these types of systems). When installing REC solar panels on fixed position (e.g., anchored)
water platforms, for example, floating pontoons, follow the instructions below specific to such applications. Failure to do so will invalidate
the warranty.
NOTE For all installations on water platforms, first advise REC before the start of installation in case of any site specific
instructions or constraints.
INSTALLATION ENVIRONMENT
Installation site
• REC solar panels may only be installed on closed bodies of fresh water where water salinity does not exceed PSU (
mS/cm at °C). This specifically excludes mounting on sea and ocean applications.
• The maximum permitted wave height must not exceed m from the crest to the trough of the wave.
Floating platforms
• When using a floating platform, follow the manufacturer’s instructions regarding installation, maintenance, inspection and
cleaning at all times.
Minimum installation height
• The minimum installation height of REC solar panels on floating platform systems is in ( cm) and is defined as the
height between the water surface and the lowest edge/part of the panel during normal operation. This will help to shield
the panel from direct water spray.
INSTALLATION INSTRUCTIONS
System installation
• All cables used for the installation must have sufficient length and slack to prevent damage due to water level changes
and wave motions.
NOTE Negative system grounding is required for REC solar panels installed on a floating platform.
Mounting panels
• Installation of REC solar panels must be in accordance with the aforementioned standard mounting instructions.
• The junction box should be oriented as far as possible from the water surface according to system design and the junction
box, cables and connectors must be protected from direct water splash.
• The installation must allow for sufficient spacing between individual panels, in order to avoid all contact as caused by the
natural movement and flexing of the floating structure.
Panel protection
• In areas with high avian activity, additional bird repelling devices may be installed as long as they do not adversely affect
system performance, e.g., shading or to the local environment etc.
• If using lightning protection equipment on the floating installation, all relevant local regulations must be respected.
MAINTENANCE
• Regularly inspect the installation to ensure all panels are securely mounted.
NOTE
For installations with high avian activity, system cleaning may be required at more frequent intervals to reduce
shading of panels caused by bird defecation.
Safety
• Immediately disconnect the system if the installation or the floating platform exhibits deviation from standard operating
conditions.
• In the event of the floating platform being submerged, disconnect the DC connection at the inverter immediately. Do not
attempt to salvage panels when sunlight is present.
