11. Parts Diagram & List - RSDE2 & RSDE2-A
3
1
4
6
7
2
8
18
9
10
12
15
11
16
19
13
14
17
5
20
1 1
21
22
No. Ref. Number Description Quantity No. Ref. Number Description Quantity
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
CBKS
ZASE
ZANA
ZAMS
ZAMT
ZAMI
ACGN
ZAPH
ZAST
ZAMN
ZAVB
ZAVA
ZAVI
ZAVJ
ZAND
ZASC
RSDE/B
ZAMV
DX100X
ZAVK
Illuminated Switch
Round Ferrite
Hood
Suppressor
P Clip Suppressor Fixing
Cable Gland
Cable Gland Nut
3M Cable With UK Plug
Drum Lid
Motor with Leads & Gasket
Paper Filter Bag
Cartridge Filter
102-32mm Reducer
2M x 32mm Hose
Side Inlet
Drum
Castor Set
100mm x 2m PVC hose, LH helix, per metre
102mm Hose Cuff
32mm Hose Cuff
3 Pin Plug Socket (RSDE2-A only)
Circuit Board (RSDE2-A only)
1/2
1
1
1
1
1
1
1
1
1
6
1
1
1
1
1
1
2
1
1
1
1
