Red Fire 10 - Technical Specifications

8
Series
User manual | REDFIRE Series
ITALIANO
Serie REDFIRE | Manuale d’uso
9
INDICE
1 | Introduzione 10
2 | Installazione 10
3 | Descrizione 11
3.1 | Ingressi e controlli 11
3.2 | Alimentazione 13
4 | Soluzione dei problemi 14
5 | Dati tecnici 15
6 | Note 16
Le avvertenze nel presente manuale devono essere osservate
congiuntamente al “Manuale d’uso - Sezione 2”.
CONTENUTO DELL’IMBALLO
• 1x Diffusore Fullrange Attivo
• 1x Cavo di alimentazione (VDE)
• 1x Manuale d’uso - Sezione 1
• 1x Manuale d’uso - Sezione 2
5
| TECHNICAL SPECIFICATIONS
REDFIRE 10 REDFIRE 12 REDFIRE 15
System type
Vented enclosure,
2-way
Vented enclosure,
2-way
Vented enclosure,
2-way
LF
10” custom woofer
1.5” VC
12” custom woofer
2” VC
15” custom woofer
2” VC
HF
1” compression
driver - 1” VC
1” compression
driver - 1.35” VC
1” compression
driver - 1.35” VC
Coverage 80° H x 55° V 90° H x 60° V 90° H x 60° V
Amplier (LF+HF) Class D + Class A/B Class D + Class A/B Class D + Class A/B
Peak Power (LF+HF) 500 W 800 W 800 W
Frequency response 60 Hz - 20 kHz 50 Hz -20 kHz 45 Hz -20 kHz
SPL - Max 120 dB 122 dB 123 dB
I/O Connectors
MIC: Combo
LINE IN: XLR-F +
jack 6,35mm (1/4”)
AUX IN: mini-jack
3,5mm
LINE OUT: XLR-M
MIC: Combo
LINE IN: XLR-F + jack
6,35mm (1/4”)
AUX IN: mini-jack
3,5mm
LINE OUT: XLR-M
MIC: Combo
LINE IN: XLR-F + jack
6,35mm (1/4”)
AUX IN: mini-jack
3,5mm
LINE OUT: XLR-M
Controls
MIC LEVEL,
LINE/AUX LEVEL,
LOW EQ, HIGH EQ,
MASTER LEVEL
MIC LEVEL,
LINE/AUX LEVEL,
LOW EQ, HIGH EQ,
MASTER LEVEL
MIC LEVEL,
LINE/AUX LEVEL,
LOW EQ, HIGH EQ,
MASTER LEVEL
Fuse T2A L 250V~ T3.15A L 250V~ T3.15A L 250V~
Suspension system 2 x M8 - under 4 x M10 - top/under
5 x M10 - top/under/rear
Cabinet Polypropylene Polypropylene Polypropylene
Dimensions (WxHxD)
321 x 505 x 307 mm
12.6” x 19.8” x 12.1”
385 x 597 x 366 mm
15.1” x 23.5” x 14,4”
460 x 705 x 440 mm
18.1” x 31.3” x 17.3”
Weight 12 kg (26.4 lb) 17,3 kg (38.1 lb) 21,1 kg (46.4 lb)
EMI CLASSIFICATION
According to the standard EN55103 this equipment is designed and suitable to operate in E3 (or
lower E2, E1) electromagnetic environments.
