red lion TCU Product Manual

9
ORDERING INFORMATION
MODELS WITHOUT SECOND INPUT OPTIONS
HEATER CURRENT MONITOR MODELS (HCM)
SECOND ANALOG INPUT MODELS (ANA)
MOTORIZED VALVE POSITIONER MODELS (MVP)
ACCESSORIES
9
Type 4X/IP65
BEZEL
4 to 20 mA
ANALOG
OUTPUT
0 to 10 VDC
ANALOG
OUTPUT
ALARM
OUTPUTS
COOLING
OUTPUT
RS485 COM
PART NUMBER
115/230 VAC
NO NO NO NO NO NO TCU00000
NO NO NO 2 NO NO TCU00001
NO NO NO 1 YES NO TCU00002
NO YES NO 2 NO NO TCU01001
NO YES NO 2 NO YES TCU01004
NO YES NO 1 YES YES TCU01005
YES NO NO NO NO NO TCU10000
YES NO NO 2 NO NO TCU10001
YES NO NO 1 YES NO TCU10002
YES YES NO 2 NO NO TCU11001
YES YES NO 1 YES NO TCU11002
YES YES NO 2 NO YES TCU11004
YES YES NO 1 YES YES TCU11005
YES NO YES 2 NO NO TCU12001
YES NO YES 2 NO YES TCU12004
YES NO YES 1 YES YES TCU12005
These models have dual alarm outputs, or single alarm with cooling outputs, with shared common terminals (Form A
Type). As a result, these outputs should be fitted with the same type of output module. The main output (OP1) may be
fitted with any type of output module.
Type 4X/IP65
BEZEL
4 to 20 mA
ANALOG
OUTPUT
0 to 10 VDC
ANALOG
OUTPUT
ALARM
OUTPUTS
COOLING
OUTPUT
RS485 COM PART NUMBER
YES NO NO 2 NO YES TCU10204
YES YES NO 2 NO NO TCU11208
These models have dual alarm outputs, or single alarm with cooling outputs, with shared
common terminals (Form A Type). As a result, these outputs should be fitted with the same type
of output module. The main output (OP1) may be fitted with any type of output module.
Type 4X/IP65
BEZEL
4 to 20 mA
ANALOG
OUTPUT
0 to 10 VDC
ANALOG
OUTPUT
ALARM
OUTPUTS
COOLING
OUTPUT
RS485 COM PART NUMBER
YES NO NO 2 NO YES TCU10104
YES YES NO 2 NO NO TCU11108
YES NO YES 2 NO NO TCU12108
These models have dual alarm outputs, or single alarm with cooling outputs, with shared
common terminals (Form A Type). As a result, these outputs should be fitted with the same
type of output module. The main output (OP1) may be fitted with any type of output module.
Type 4X/IP65
BEZEL
4 to 20 mA
ANALOG
OUTPUT
0 to 10 VDC
ANALOG
OUTPUT
ALARM
OUTPUTS
COOLING
OUTPUT
RS485 COM PART NUMBER
YES NO NO 1 NO YES TCU10307
YES YES NO 1 NO NO TCU11306
YES NO YES 1 NO NO TCU12306
DESCRIPTION PART NUMBER
Relay Module OMD00000
Triac Module OMD00001
Logic/SSR Drive Module OMD00003
45 A Single Phase Panel Mount SSR RLY50000
25 A Single Phase DIN Rail Mount SSR RLY60000
40 A Single Phase DIN Rail Mount SSR RLY6A000
25 A Three Phase DIN Rail Mount SSR RLY70000
50:0.1 Ampere Current Transformer CT005001
40:0.1 Ampere Current Transformer CT004001
Note: Output Modules are NOT supplied with the controller. When specifying the controller, be
sure to purchase the appropriate output module for the Main Control Output and if necessary,
the alarm output(s), the cooling output, and valve positioner outputs. The controller can be
fitted with any combination of output modules.
The Logic/SSR Drive Module is a switched DC source, intended to drive the DC input of an
SSR power unit. It should never be connected to line voltage.
All output modules are packaged separately and must be installed by the user.
