Befor e assembl y rea d instructio n carefully.Assembl e gril l o n a clean , fla t surface . Thi s
uni t i s heavy .
2 . Turn the Firebox(18) assembly upside
down. Attach the legs (36) and fire rod
(39) to the Lid&Firebox (18) using M6 x 12
bolts (D) for each corner. The fire rod (39)
in the left. Only hand tighten until all bolts
are in, then tighten with a Phillips
screwdriver.
3 . Us e hardwar e M6 x 12 bolts ( D) t o
attac h th e botto m shel f ( 28 ) t o legs .
Als o assembl e th e ga s tan k hoo k an d
ga s tan k holde r ( 1 9,35 ) a s show n
usin g hardwar e M6 x 12 bolts ( D).
Mak e sur e i t i s place d unde r th e ga s
sectio n o f th e grill . Thi s i s th e sectio n
wit h th e ven t slot s in th e body .
1. Attach the g as Lid(18 -1 ) and charcoal
lid(18-2) to the firebox (17) by insert ing
h inge pins ( I ) through the holes on the
upper hinges and lower hinges Insert
cotter pins ( J ) into the ends of the hinge
pins ( I ).
