3-DRAWINGS AND TECHNICAL CHARACTERISTICS
TECHNICAL CHARACTERISTICS COMPACT 18 EASY CLEAN - 2015 COMPACT 24 EASY CLEAN
Product class (EN 303-5/2012) 5 5
Rated thermal capacity of the rebox 18.0 kW (15480 kcal/h) 24.5 kW (21070 kcal/h)
Nominal output power: 16.8 kW (14448 kcal/h) 22.1 kW (19006 kcal/h)
Minimum output power 4.6 kW (3956 kcal/h) 3.8 kW (3268 kcal/h)
Eciency at Max 93.7% 90.2%
Eciency at Min 90.5% 88.5%
Temperature of exhaust smoke at Max 110°C 150°C
Temperature of exhaust smoke at Min 60°C 60°C
Max congurable temperature 80°C 80°C
Max operating temperature 95°C 95°C
Particles/OGC/Nox (10%O
2
) 24.6 mg/Nm
3
- 1 mg/Nm
3
- 180 mg/Nm
3
24 mg/Nm
3
- 0.1 mg/Nm
3
- 181 mg/Nm
3
CO at 10% O
2
at Min and at Max 0.029 - 0.010% 0.027 - 0.013%
CO
2
at Min and at Max 6.7 - 10.0% 5.9 - 9.0%
Recommended draught at Max power 0.10 mbar - 10 Pa 0.10 mbar - 10 Pa
Recommended draught at Min power 0.05 mbar - 5 Pa 0.05 mbar - 5 Pa
Smoke mass 10.7 g/sec 17.5 g/sec
Hopper capacity 100 litres 100 litres
Type of pellet fuel Pellet diameter 6-8 mm and size 3/40 mm Pellet diameter 6-8 mm and size 3/40 mm
Pellet hourly consumption Min ~ 1,1 kg/h* - Max ~ 3,7 kg/h* Min ~ 1 kg/h* - Max ~ 4.8 kg/h*
Autonomy At min ~ 59 h* - At max ~ 18 h* At min ~ 68 h* - At max ~ 15 h*
Heatable volume m
3
361/40 - 413/35 - 482/30** 475/40 - 543/35 - 634/30**
Water content 25 litres 25 litres
Max operating temperature 3 bar - 300 kPa 3 bar - 300 kPa
Combustion air inlet  80 mm  80 mm
Smoke outlet  100 mm  100 mm
Air intlet 100 cm
2
100 cm
2
Rated electrical power (EN 60335-1) 180 W (Max 430 W) 180 W (Max 430 W)
Supply voltage and frequency 230 Volt / 50 Hz 230 Volt / 50 Hz
Net weight 220 kg 220 kg
Weight with packaging 240 kg 240 kg
* Data that may vary depending on the type of pellets used.
** Volume that can be heated, according to the power requirement in m
3
(respectively 40-35-30 Kcal/h per m
3
)
