4-UNPACKING
Technical Dept. - All rights reserved - Reproduction is prohibited
Install the boiler in the area set aside for it, making sure it conforms to the requirements. The boiler body or unit must always be kept in a
vertical position when moved, and only ever moved using suitable lifting trolleys.
The packaging materials are neither toxic nor harmful, and therefore no particular disposal measures are required.
After removing all the packaging, check that the boiler is complete and not damaged. If in doubt, contact the retailer.
As shown in gure 3, the product has a hook to lift up the boiler.
To use the hook, lift the front cover, take the hook from the bag with the instructions and secure it to the bracket under the front cover.
The following documents are provided in the package:
• Instruction booklet
• Inspection and maintenance report
• Accessory
FIGURE 3 - LIFTING HOOK
