26
A
b
d
c
e
f
6-ASSEMBLY
Live electrical parts: only power the product after completing assembly.
COMPRESSOR CONNECTION
A COMPRESSOR d KNOCKOUT HOLE ON REAR BOILER PANEL
b COMPRESSOR PIPE FASTENING SCREWS (supplied)
c SOLENOID VALVE e GASKET (supplied)
f POLYSTYRENE
