RED RANGER GEMINI 5K S35 User Manual

C OPYRIGH T © 20 20 R ED .COM, LL C 95 5- 0192_V7 .3 , R EV- A | 8
RED RANGER GEMINI OPERATION GUIDE
CHAPTER 1:
PRODUCT INTRODUCTION
Figure: RED RANGER GEMINI
RED RANGER GEMINI is an integrated 5K S35 camera system offering an all-in-one system for top-tier production use.
It features all of the benefits of the GEMINI 5K S35 sensor within a compact and less complex platform for filmmakers.
Features like integrated I/O’s, 24V power out, shimmed PL Mount, and improved thermal performance offer unmatched
versatility as well as peace of mind in challenging shooting environments.
RED RANGER GEMINI is capable of handling the rigorous strain and robust power needs of high-end studio productions.
RED RANGER GEMINI supports wide input voltage (11.5V to 32V), offers independent SDI and AUX power outputs,
and features an integrated XLR audio input. The camera also boasts a larger fan for quieter and more efficient
temperature management. RED RANGER GEMINI is available in two configurations, supporting either V-Lock or Gold
Mount batteries.
This section introduces the imaging capabilities and advanced features of the camera system.
This guide is for the following cameras only:
SENSOR TYPE CAMERA
GEMINI 5K S35 RED RANGER GEMINI 5K S35 (V-Lock)
RED RANGER GEMINI 5K S35 (Gold Mount)

RED RANGER GEMINI 5K S35 Specifications

General

Brand	RED
Model	RANGER GEMINI 5K S35
Category	Digital Camera
Language	English
