7
1 INTRODUCTION
27 (1.063)
74 (2.913)
186 (7.323)
21 (0.827)
29 (1.142)
185 (7.283)
429 (16.890)
445 (17.520)
404 (15.906)
82 (3.228)
79 (3.110)
Figure 1.4.1 - Main Unit Dimensions - in mm (inches)
Figure 1.4.2 - Remote Monitor Dimensions - in mm (inches)
