Specifications
4 Input Channel Functions
CH1 MIC/LINE: XLR/TRS combination 1x Mono
– includes MIC to CH1 Headset
Gain, -14~40dB
PAD: -20dB
CLIP +6dB (LED turns on when 3dB below clip )
EQ LOW/MID/ HIGH: 80Hz, 2.5KHz, 12 KHz (+/-15dB)
PHANTOM POWER: +48V LED
Fader Level
EFFECT: Digital Echo on CH1 (DELAY, LEVEL, MUTE)
CH2 INST: 1x Mono (LINE/GUITAR
with impedance switch)
CH 3-CH4: 1x Stereo (LINE – L/Mono & R)
LINE/INST-HI-Z Switch
Signal LED: -3dB
Level Knob
Signal LED: -3dB
Level Knob
Output Channels
MAIN L/R Out: 1
PHONES: 2x Stereo (includes HEADSET phones 3.5mm)
1x Stereo + Effects
2x2 point L/R LED meter (CLIP, SIG)
DC 5V, 500 mA (via USB)
Max. 2.5W
124 x 40 x 157 mm
0.67kg
Stereo Input / Output
USB Audio Class 2.0 – like external sound card to PC
Sampling Frequency: Max 48KHz
Bit Depth: 16-Bit
Connector: Type B
Signal LED: -3dB
Playback LEVEL Knob
Stereo ADC: THD+N=0.01%; snr=89 dB;
Dynamic Range = 89 dB; OUTPUT
BUS
LEVEL METER
POWER REQUIREMENT
POWER CONSUMPTION
DIMENSIONS
WEIGHT
USB AUDIO Input and Output
Stereo DAC: THD+N=0.005%; snr=96 dB;
Dynamic Range =93 dB; INPUT
Specifications
