Assembly
1) With assistance, remove ATV from crate bottom and place on ATV jack.
2) Front Brakes
a. Remove blue ties holding front brake plate to ATV.
b. Remove 21mm hex castle nut and washer from front steering knuckle.
c. Line up slot in brake plate with locating tab on steering knuckle.
d. Slide brake assembly into place.
10
