Redfox FTH 30 G - Page 48

Model Burner
Power
(kW)
Dimensions of
plate
(cm)
Dimensions
(cm)
FTH 30 G 1x 4,0 kW 4,0 32 x 48 33 x 60 x 22 v
FTR 30 G 1x 4,0 kW 4,0 32 x 48 33 x 60 x 22 v
FTH 60 G 2x 4,0 kW 8,0 65 x 48 66 x 60 x 22 v
FTHR 60 G 2x 4,0 kW 8,0 65 x 48 66 x 60 x 22 v
FTHC 30 G 1x 4,0 kW 4,0 32 x 48 33 x 60 x 22 v
FTRC 30 G 1x 4,0 kW 4,0 32 x 48 33 x 60 x 22 v
FTHC 60 G 2x 4,0 kW 8,0 65 x 48 66 x 60 x 22 v
FTHRC 60 G 2x 4,0 kW 8,0 65 x 48 66 x 60 x 22 v
FTH 90 G 3x 4,0 kW 12,0 97 x 48 99 x 60 x 22 v
FTHC 90 G 3x 4,0 kW 12,0 97 x 48 99 x 60 x 22 v
FTHR 90 G 3x 4,0 kW 12,0 97 x 48 99 x 60 x 22 v
MODEL NOZZLE Burner
12,8 kWh/kg
G 30/G 31
PROPAN /
BUTAN
28 - 30 mbar
12,8 kWh/
kg
G 31
PROPAN
37 mbar
12,8 kWh/kg
G 30/G 31
PROPAN / BUTAN
50 mbar
9,45 kWh/
m
3
G 20
Natural GAS
20 mbar
FEEDING
TUBE
GAS
FT**-30
NOZZLE OF BURNER 1/100 MM 4,0 kW 93 93 77 135 G 1/2“
CONSUPTION 4,0 kW 0,546 kg/h 0,546 kg/h 0,546 kg/h 0,74 m
3
/h ---
FT**-60
NOZZLE OF BURNER 1/100 MM 2x 4,0 kW 93 93 77 135 G 1/2“
CONSUPTION 2x 4,0 kW 1,092 kg/h 1,092 kg/h 1,092 kg/h 1,148 m
3
/h ---
FT**-90
NOZZLE OF BURNER 1/100 MM 3x 4,0 kW 93 93 77 135 G 1/2“
CONSUPTION 3x 4,0 kW 1,638 kg/h 1,638 kg/h 1,638 kg/h 2,22 m
3
/h ---
BURNERS
48
