Redfox FTH 30 G - Technical Data and Burner Specifications; Technical Data Overview; Burner Performance Details

Model Burner
Power
(kW)
Dimensions of plate
(cm)
Dimensions
(cm)
FTH 30 GL 1x 4,0 kW 4,0 32 x 48 33 x 60 x 29 v
FTR 30 GL 1x 4,0 kW 4,0 32 x 48 33 x 60 x 29 v
FTH 60 GL 2x 4,0 kW 8,0 65 x 48 66 x 60 x 29 v
FTHR 60 GL 2x 4,0 kW 8,0 65 x 48 66 x 60 x 29 v
FTHC 30 GL 1x 4,0 kW 4,0 32 x 48 33 x 60 x 29 v
FTRC 30 GL 1x 4,0 kW 4,0 32 x 48 33 x 60 x 29 v
FTHC 60 GL 2x 4,0 kW 8,0 65 x 48 66 x 60 x 29 v
FTHRC 60 GL 2x 4,0 kW 8,0 65 x 48 66 x 60 x 29 v
FTH 90 GL 3x 4,0 kW 12,0 97 x 48 99 x 60 x 29 v
FTHC 90 GL 3x 4,0 kW 12,0 97 x 48 99 x 60 x 29 v
FTHR 90 GL 3x 4,0 kW 12,0 97 x 48 99 x 60 x 29 v
FTHRC 90 GL 3x 4,0 kW 12,0 97 x 48 99 x 60 x 29 v
MODEL NOZZLE Burner
12,8 kWh/kg
G 30/G 31
PROPAN / BUTAN
28 - 30 mbar
12,8 kWh/kg
G 31
PROPAN
37 mbar
12,8 kWh/kg
G 30/G 31
PROPAN / BUTAN
50 mbar
9,45 kWh/m
3
G 20
ERDGAS
20 mbar
GASAN-
SCHLU-
SSROHR
FT**-30 GL
NOZZLE OF BURNER 1/100 MM 4,0 kW 93 93 77 135 G 1/2“
CONSUPTION 4,0 kW 0,546 kg/h 0,546 kg/h 0,546 kg/h 0,74 m
3
/h ---
FT**-60 GL
NOZZLE OF BURNER 1/100 MM 2x 4,0 kW 93 93 77 135 G 1/2“
CONSUPTION 2x 4,0 kW 1,092 kg/h 1,092 kg/h 1,092 kg/h 1,148 m
3
/h ---
FT**-90 GL
NOZZLE OF BURNER 1/100 MM 3x 4,0 kW 93 93 77 135 G 1/2“
CONSUPTION 3x 4,0 kW 1,638 kg/h 1,638 kg/h 1,638 kg/h 2,22 m
3
/h ---
BURNERS
DECLARATION OF A STANDARDS CONFORMITY
The producer confi rms that the devices agree with 2016/426/EU, 2014/30/EU, 2014/35/EU standards,
rule nr. 22/1997 sb., nr. 258/2000 sb., nr. 258/200 sb.,
nr. 118/2016 sb., 117/2016 sb. and with relevant
goverment orders. Instalation must be done with respect to valid standards. Attention, the producer refuses
any responsibility in case of direct or indirect damages which are caused due to wrong instalation, incorrect
intervention or modifi cation, insuffi cient maintenance, incorrect use and also possibly caused by other
reasons presented by items in sale conditions. This appliance is set only for skilled use and must be operated
by qualifi ed persons only. Parts set and secured by the producer or accredited person must not be rebuilt by
user.
TECHNICAL DATA
Label with technical data is placed on the back side of the device. Study the electrical diagram of connection
and all following information before instalation.
