Example installation with SARG1 system.:
During system installation, we must ensure the possibility of flow regardless of the position of the zone valve at the
time of power failure. Therefore, in the case of systems with a buffer connected in series or without it, we can
provide heat collection, e.g. from short floor heating loops not controlled by an actuator, or make a bypass to the hot
water tank with a normally open solenoid valve, which will open after a power failure.
Characteristics of the circulation pump:
