■ CONNECTING SWITCH WIRES
•Connect the switch wires between the
engine and the main unit. Pair the wires of
the same color.
■ PUTTING ON WAIST PAD
(BC4400DW only)
•Warp the waist pad around the shaft tube
and the throttle wire.
❲
10
❳
Set up
■ INSTALLING CUTTING HEAD
1.While locking the gear shaft by inserting
the attached bar into the upper holder and
the gear box, loosen and remove the
hexagon bolt(left-handed)
2.Fit the spacer attached to the head
assembly between the upper and lower
holders. Then screw in the cutting head to
the gear shaft over the holders. Hand-
tighten it securely.
