RedMax BC2300DL - Page 27

Fig.1 DRIVE UNIT BC2300DL & BC2600DL
Key# Description Part Number Q'ty
1 HOUSING, ASS’Y 6460-11002 1
2 CUSHION 6470-31230 1
3 BRACKET (A) 6460-31210 1
4 BRACKET (B) 6460-31220 1
5 BOLT 01252-30514 1
6 BOLT 01252-30530 2
7 DRUM, clutch 6460-12111 1
8 SNAP, ring 04065-02812 1
9 BEARING 06004-06001 1
10 SNAP, ring 04064-01210 1
11 BOLT 6468-91150 4
12 HANGER COMP. 6460-17100 1
13 HANGER 9366-17110 1
14 CLAMP 6460-17120 1
15 SCREW 0263-90525 1
16 LEVER ASS'Y 181124 1
17 THROTTLE LEVER 181689 1
18 SCREW 145569 1
19 SCREW 180974 4
20 SPRING 610314 1
21 STOP SWITCH 180252 1
22 CORD, red 180768 1
23 CORD, black 180769 1
24 CABLE COMP. 6502-82100 1
25 GEARCASE ASS'Y 6460-13000 1
26 GEARCASE 6460-13110 1
27 BEARING 6460-13410 1
28 BEARING 6460-13420 1
29 BEARING 6460-13430 1
30 BEARING 06001-06001 1
31 GEAR 6460-13220 1
32 SHAFT 6460-13210 1
33 PINION 6460-13310 1
34 OIL SEAL 6460-13140 1
35 SNAP RING 6460-13340 1
36 SNAP RING 6460-13350 1
37 HOLDER(A) 6460-13240 1
38 HOLDER(B) 6460-13250 1
39 BOLT 6460-13290 1
40 WASHER 6460-13370 1
41 BOLT 01252-50512 1
42 BOLT 01252-50525 1
43 FITTING, grease 6460-13360 1
44 GUARD ASS'Y 6460-24000 1
45 GUARD COMP. 6460-24100 1
46 BLADE 6041-24140 1
47 SCREW 0263-30512 2
48 NUT 3320-15310 2
49 CLAMP 3541-24121 1
50 BOLT 3540-24130 2
51 WASHER 0290-20615 2
52 HANDLE ASS'Y 6462-14100 1
53 HANDLE 6462-14310 1
54 CLANP 6462-14320 1
55 SCREW 0263-90535 4
56 COM. TAP HEAD 4" PT104 1
57 CASE 6460-15112 1
58 CORD HOLDER 6460-15141 1
59 COVER 6460-15131 1
60 PLATE, large 3268-15150 1
Key# Description Part Number Q'ty
61 SPRING 6041-99161 1
62 PLATE, small 3268-15170 1
63 CORD 6460-15180 1
64 SPACER 6460-15210 1
65 SHAFT PTA008 1
66 GOGGLE 180773 1
67 STRAP ASS'Y 160197 1
68 TOOL KIT 3550-91000 1
69 SCREWDRIVER 1030-91340 1
70 SOCKET 3239-91310 1
71 WRENCH 09007-00425 1
72 BAR 3540-91110 1
73 SPANNER 3540-91120 1
74 PIPE COMP. 180771BC 1
75 SHAFT 3520-12212 1
76 GRIP 180770 1
77 DECAL 181127 1
