29
❳
Fig.2 ENGINE UNIT BC2300DL
Key# Description Part Number Q'ty
1 CYLINDER 5580-12110 1
2 GASKET,base 5500-12212 1
3 BOLT 1850-12130 2
4 INSULATOR 5500-13162 1
5 GASKET,insulator 5500-13121 1
6 GASKET,carburetor 5500-13131 1
7 SCREW 0263-90520 2
8 MUFFLER ASS'Y 5850-15100 1
9 –––––– ––––– –
10 ARRESTER 1601-15120 1
11 BOLT 01252-30550 2
12 GASKET,muffler 5910-15211 1
13 PLATE,muffler 5500-15220 1
14 SCREW 0263-90416 1
15 CRANKCASE COMP. 5500-21100 1
16 GASKET,case 5500-21141 1
17 BEARING 06030-06001 2
18 OIL SEAL 2169-21210 1
19 OIL SEAL 1850-21220 1
20 SNAP RING 04065-02812 1
21 SCREW 01252-30530 4
22 PISTON 5600-41111 1
23 RING 1100-41210 2
24 PIN 1101-41310 1
25 SNAP RING 1260-41320 2
26 BEARING 1140-41330 1
27 WASHER 1101-41340 2
28 CRANKSHAFT COMP. 5500-42001 1
29 NUT 1650-43230 1
30 KEY 1000-43240 1
31 SHOE,clutch 1140-51111 2
32 SCREW 1140-51250 2
33 SPRING 1970-51221 1
34 WASHER 1140-51230 2
35 WASHER 1970-51241 2
36 ROTOR 5501-71110 1
37 COIL ASS'Y 5501-71201 1
38 CORD 5500-71220 1
39 CAP 2616-71320 1
40 CAP 1900-72111 1
41 SPRING 1900-72120 1
42 GROMMET 5500-72130 1
43 SPACER 1260-71261 2
44 BOLT 3310-72150 2
45 RECOIL ASS'Y 5500-75100 1
46 CASE COMP. 5500-75110 1
47 REEL 1850-75120 1
48 SPRING,spiral 1850-75130 1
49 SCREW 1850-75151 1
50 ROPE 1850-75160 1
51 KNOB 1140-75320 1
52 PLATE,stopper 5500-75170 1
53 PULLEY ASS'Y 1850-75201 1
54 RATCHET 1850-75221 1
55 SPRING 1850-75230 1
56 SCREW 0263-90416 4
57 CARBURETOR ASS'Y 5501-81000 1
58 SCREW 1752-81110 2
59 BRACKET 5500-81120 1
60 RING 1751-81130 1
Key# Description Part Number Q'ty
61 SWIVEL 1881-81140 1
62 VALVE ASS'Y ––––– 1
63 SCREW,adjuster 1918-81170 1
64 NUT,adjuster 1751-81180 1
65 RING 1881-81130 1
66 O-RING 1751-81240 1
67 JET 5500-81251 1
68 DIAPHRAGM 3310-81260 1
69 GASKET,pump 1065-81410 1
70 DIAPHRAGM,pump 1065-81420 1
71 BODY ASS'Y 1850-81450 1
72 SCREEN 3306-81380 1
73 GASKET,diaphragm 1850-81470 1
74 BODY,purge 1850-81490 1
75 PUMP,priming 1751-81510 1
76 COVER,pump 1850-81520 1
77 SCREW 1850-81530 4
78 WASHER 5500-81160 1
79 SCREW 0263-90560 2
80 BODY ASS'Y 5500-82102 1
81 SLEEVE 1970-82190 2
82 PLATE,choke 5500-82131 1
83 LEVER,choke 5500-82140 1
84 SCREW 2630-33610 1
85 ELEMENT 5500-82171 1
86 COVER ASS'Y 5600-82202 1
87 KNOB 5500-82221 1
88 COVER,fan 5501-31111 1
89 SCREW 0263-90520 4
90 COVER,engine 5580-32112 1
91 SCREW 1850-32160 1
92 SCREW 1900-31410 2
93 GUARD,plug 5500-32210 1
94 SCREW 0263-90514 1
95 SPARKPLUG 5602-73110 1
96 GROMMET 1852-72121 1
97 CORD COMP. 5501-73201 1
98 TANK ASS'Y 5500-85004 1
99 CAP ASS'Y 5601-85200 1
100 HOLDER 5601-85230 1
101 CAP,holder 5600-85240 1
102 VALVE 5600-85250 1
103 PACKING 5500-85220 1
104 PIPE COMP. 5500-85300 1
105 FILTER ASS'Y 5500-85400 1
106 CLIP 1260-85460 1
107 SCREW 5500-85510 3
108 CLIP 1950-86120 1
109 LABEL 5501-91122 1
110 RING 5500-82230 1
111 VALVE 3356-81310 1
112 SPRING 1850-81270 1
113 SCREW 1850-81220 1
114 PIN 3310-81250 1
115 LEVER 3310-81230 1
116 PIN 2629-21130 3
To Next Page
