35
❳
Fig.5 ENGINE UNIT BC3400DL
(S/N 980101 and up)
Key# Description Part Number Q'ty
1 CYLINDER 4700-12110 1
2 BOLT 3310-12281 4
3 GASKET,base 4500-13120 1
4 CRANKCASE COMP. 4500-21100 1
5 • PIN 2629-21130 3
6 GASKET,case 4500-21140 1
7 BEARING 06030-06201 2
8 OIL SEAL 4810-21210 1
9 OIL SEAL 1650-21220 1
10 BOLT 01252-30530 4
11 SNAP RING 04065-03212 1
12 PISTON 4700-41110 1
13 RING 1650-41210 2
14 PIN 1030-41310 1
15 RING 1300-41320 2
16 BEARING T2100-41410 1
17 WASHER 2850-41510 2
18 CRANKSHAFT COMP. 4500-42000 1
19 SHOE,clutch 1400-51111 2
20 SPRING 1651-51220 1
21 SCREW 1200-51211 2
22 WASHER 1200-51230 2
23 WASHER 1200-51241 2
24 ROTOR 4700-71110 1
25 COIL ASS'Y 4700-71200 1
26 • CORD 4700-71220 1
27 • CAP 4700-71230 1
28 • PIN 4700-71240 2
29 GROMMET 5500-72130 1
30 CAP,plug 1900-72111 1
31 SPRING 1900-72120 1
32 BOLT 4500-72150 2
33 NUT 1650-43230 1
34 KEY 1000-43240 1
35 MUFFLER ASS'Y T1006-15100 1
36 • ARRESTER 1601-15120 1
37 BOLT 01252-30560 2
38 BOLT 3310-31720 1
39 GASKET 4700-15210 1
40 PLATE 4500-15220 1
41 SCREW 0263-90514 1
42 COVER 4700-31110 1
43 BOLT 3310-12281 4
44 PLATE 4700-31210 1
45 COVER 4500-32110 1
46 SCREW 4500-32120 4
47 GUARD 4500-32210 1
48 SPARKPLUG 5602-73110 1
49 GROMMET 1852-72121 1
50 CORD T1006-73220 1
51 CORD,earth T1006-73230 1
52 CLAMP 1140-72231 1
53 RECOIL ASS'Y 4500-75100 1
54 • REEL 4500-75120 1
55 • SCREW 4500-75150 1
56 • SPRING,spiral 1850-75130 1
57 • COLLAR 4500-75180 1
58 • ARM 4500-75190 1
59 • ROPE 4500-75160 1
60 • KNOB 1140-75320 1
Key# Description Part Number Q'ty
61 • PLATE,stopper 5500-75170 1
62 PULLEY 4500-75210 1
63 SCREW 4500-75511 4
64 COLLAR 4700-75310 1
65 INSULATOR 4500-13160 1
66 SCREW 4500-13180 2
67 GASKET,insulator 4700-13150 1
68 GASKET,carburetor 4500-13130 1
69 CARBURETOR ASS'Y T1006-81000 1
70 • REBUILT KIT 5602-06030 1
71 • • BODY ASS'Y 1850-81450 1
72 • • • SCREEN ––––––––– –
73 • • • VALVE ––––––––– –
74 • • • SPRING ––––––––– –
75 • • • SCREW ––––––––– –
76 • • • PIN ––––––––– –
77 • • • LEVER ––––––––– –
78 • • GASKET KIT 5602-06020 1
79 • • • DIAPHRAGM ––––––––– –
80 • • • GASKET,diaphragm ––––––––– –
81 • • • DIAPHRAGM,pump ––––––––– –
82 • • • GASKET,pump ––––––––– –
83 • BODY,purge 1850-81490 1
84 • COVER,pump 1850-81520 1
85 • PUMP,priming 1751-81510 1
86 • JET T1006-81250 1
87 • O-RING 1751-81240 1
88 • RING 1751-81130 1
89 • SWIVEL 1881-81140 1
90 • VALVE ASS'Y ––––––––– 1
91 • SCREW 1752-81110 2
92 • BRACKET 5500-81120 1
93 • NUT,adjuster 1751-81180 1
94 • SCREW,adjuster 1918-81170 1
95 • RING 1881-81130 1
96 • SCREW 1850-81530 4
97 • WASHER 5500-81160 1
98 SCREW 0263-30550 2
99 BODY ASS'Y 4500-82100 1
100 PLATE,choke 4500-82130 1
101 LEVER,choke 4500-82140 1
102 SCREW 2630-33610 1
103 ELEMENT 4500-82170 1
104 SCREEN 4500-82180 1
105 COVER ASS'Y 4500-82200 1
106 KNOB 5500-82221 1
107 RING 5500-82230 1
108 TANK ASS'Y 4700-85000 1
109 • CAP ASS'Y 4500-85200 1
110 • • HOLDER 4500-85230 1
111 • • CAP 5600-85240 1
112 • • VALVE 5600-85250 1
113 • • PACKING 4500-85220 1
114 • PIPE COMP. 5500-85300 1
115 • FILTER ASS'Y 3302-85400 1
116 • CLIP 1260-85460 1
117 SCREW 1600-86120 4
118 LABEL,recoil T1006-75410 1
To Next Page
