Fig.6 DRIVE UNIT BC4400DW (S/N 980101 and up)
Key# Description Part Number Q'ty
1 HOUSING 4050-11110 1
2 CAP 4050-11150 1
3 JOINT 4050-11210 1
4 ABSORBER-F 4050-11250 1
5 ABSORBER-R 4050-11260 1
6 BOLT 01252-30530 4
7 BOLT 01252-30630 1
8 BOLT 01252-30510 1
9 DRUM,clutch 4050-11310 1
10 BEARING 06004-06202 1
11 SNAPRING 04065-03515 1
12 SNAPRING 04064-01510 1
13 BOLT 6468-91150 4
14 PIPE COMP 4050-12100 1
15 DRIVE SHAFT 3540-12211 1
16 HANGER ASSY 6520-17100 1
17 • HANGER 6520-17110 1
18 • CLAMP 6520-17120 1
19 • SPACER 6520-17130 1
20 • SCREW 0263-90525 1
21 BRACKET ASSY 4050-14101 1
22 • BRACKET 4050-14111 1
23 • ABSORBER 4050-14140 2
24 • CAP,Upper 3257-14192 1
25 • CAP,Lower 4050-14121 1
26 • CLAMP(A) 4050-14150 1
27 • CLAMP(B) 4050-14160 1
28 • BOLT 01252-30525 4
29 • BOLT 01252-30535 2
30 • BOLT 01252-30514 2
31 HANDLE COMP,Left 3540-14200 1
32 • GRIP 3540-14220 1
33 LEVER ASSY 6234-14601 1
34 CORD(A),black T3004-14710 1
35 CORD(B),red T3004-14720 1
36 CABLE COMP 5915-83100 1
37 TUBE T3004-14810 1
38 HANDLE COMP,Right 6242-14400 1
39 • GRIP 3540-14321 1
40 BAND 3540-93120 1
41 CLAMP 3260-14251 1
42 SCREW 0260-00516 1
43 GEARCASE ASSY T3003-13000 1
44 • GEARCASE 3541-13114 1
45 • BEARING 06000-06000 1
46 • BEARING 06000-06201 1
47 • SEAL 3180-13141 1
48 • SNAPRING 04065-03212 1
49 • BOLT 01252-30510 1
50 • FITTING,grease 3199-13350 1
51 • WASHER 01641-20608 1
52 • SHAFT 4050-13210 1
53 • GEAR 3180-13220 1
54 • WASHER 3310-43210 1
55 • WASHER 01643-30823 1
56 • BOLT,LH 3579-33260 1
57 • PINION 3541-13311 1
58 • BEARING 06001-06000 1
59 • BEARING 06000-06000 1
60 • SNAPRING 3180-13330 1
Key# Description Part Number Q'ty
61 • SNAPRING 04065-02612 1
62 • BOLT 3540-13260 1
63 • HOLDER(A) 3541-13241 1
64 • HOLDER(B) 3541-13251 1
65 GUARD ASSY 6359-24000 1
66 • GUARD COMP 6359-24100 1
67 • • BLADE 6357-24150 1
68 • • NUT 3320-15310 2
69 • • SCREW 0263-30512 2
70 • CLAMP 3541-24121 1
71 • BOLT 3540-24130 2
72 • WASHER 0290-20615 2
73 SHAFT 6041-99220 1
74 COM.TAP.HEAD 6" PT100 1
75 • CASE 6041-99111 1
76 • CORD HOLDER 6041-99140 1
77 • COVER 6041-99130 1
78 • PLATE 3268-15150 1
79 • SPRING 6041-99161 1
80 • PLATE 3268-15170 1
81 • CORD 6041-99181 1
82 • SPACER 6460-15210 1
83 PROTECTOR 4050-17110 1
84 HARNESS ASSY 6565-95200 1
85 • HOOK 6565-17210 1
86 • PLATE 6565-17220 1
87 • HANGER COMP 6565-95230 1
88 • BAND 6565-17200-01 1
89 • PROTECTOR 6565-17200-02 1
90 TOOL SET 3532-91000 1
91 • SCREW DRIVER 1030-91340 1
92 • SOCKET 3239-91310 1
93 • WRENCH 09007-00425 1
94 • WRENCH 09007-00528 1
95 • BAR 3540-91110 1
96 • SPANNER 3540-91120 1
97 GOGGLE 6242-92110 1
❲
