RedMax BCZ2401S - Page 55

55
Key# Part Number Description Q'ty
1 848-J8S-5820 PIPE COMP. 1
2 T3400-12130 • SEAL 1
3 3520-12213 SHAFT 1
4 T3195-31001 GEARCASE ASSY 1
5 848-B20-62A0 • GEARCASE 1
6 06004-06000 • BEARING 1
7 06000-00626 • BEARING 1
8 04065-02612 • RING 1
9 T3195-13210 • SHAFT 1
10 848-B20-61C0 • GEAR 1
11 T3002-13260 • NUT 1
12 848-B40-61D1 • PINION 1
13 06001-00609 • BEARING 1
14 3210-13330 • RING 1
15 04065-02412 • RING 1
16 3199-13350 • FITTING 1
17 01641-20608 • WASHER 1
18 0225-00410 • BOLT 1
19 4820-13180 • BOLT TORX 1
20 T3300-91340 • HOLDER (A) 1
21 4820-12350 • BOLT TORX 1
22 848-J80-32H2 GRIP 1
23 848-8R2-0344 LEVER COMP. 1
24 848-8R2-0314 • LEVER 1
25 6110-14410-01 • • STAY 1
26 848-8RA-0340 • • COVER 1
27 T3002-12202-03 • • LEVER 1
28 6110-14410-04 • • SCREW 2
29 6110-14410-05 • • NUT 2
30 6110-14410-06 • • SHAFT 1
31 6110-14410-07 • • SPRING 1
32 6110-14410-08 • • SPRING 1
33 T3032-14410-09 • • BUTTON 1
34 6110-14410-10 • • E-RING 1
35 T3002-12220 • CORD (A) black 1
36 T3002-12230 • CORD (B) red 1
37 T3003-14510 TUBE 1
38 1855-82100 CABLE COMP. 1
39 848-J9L-90R0 LABEL, name 1
41 T3195-14002 HANDLE ASSY 1
42 T3195-14102 • HANDLE T 1
43 T4960-53030 • SCREW 4
44 T3195-24003 GUARD ASSY 1
45 T3195-24103 • GUARD COMP. 1
46 T3002-24121 • • BLADE 1
47 T4960-51431 • • SCREW TORX 1
48 3320-15310 • • NUT 1
49 3520-24120 • CLAMP 1
50 T4950-63000 • BOLT TORX 2
Key# Part Number Description Q'ty
51 848-A56-92C0 GOGGLE 1
52 6129-61210 BAND (T) 1
53 PT104 Plus TAP HEAD COMP. 1
54 T3189-15112 • CASE 1
55 T3189-15191 • EYELET 2
56 T3189-15132 • COVER 1
57 T3189-15142 • CORD HOLDER 1
58 T3189-15160 • SPRING 1
59 T3189-15180 • CORD 1
60 6019-13250 HOLDER (B) 1
61 848-8U0-0120 TOOL-SET 1
62 3540-91110 • BAR 1
63 848-8U1-0040 • SOCKET 1
101 BC00090 BLADE KIT (PRODUCT) 1
102 5764-24000 • GUARD ASSY 1
103 5766-24110 • • GUARD 1
104 3250-24120 • • BRACKET 1
105 0225-10620 • • BOLT 2
106 0263-30614 • • SCREW 4
107 0280-10605 • • NUT 4
108 3540-13283 • COVER 1
109 6367-14200 • J-HANDLE 1
110 3583-14101 • BRACKET ASSY 1
111 6420-17300 • HANGER ASSY 1
113 9366-17110 • • HANGER 1
114 9366-17120 • • CLAMP 1
115 6420-17410 • • SLEEVE 1
116 0263-90525 • • SCREW 1
117 T3300-17100 • STRAP ASSY 1
121 SST229 9" 22-tooth 1
122 SST249 9" 24-tooth 1
123 SGB088 8" 8-tooth 1
124 SGB089 9" 8-tooth 1
125 SGB048 8" 4-tooth 1
126 SGB049 9" 4-tooth 1
Fig.1 DRIVE UNIT BCZ2401S/BCZ2401S-CA (S/N 50200101 and up)
OPTIONAL BLADE & ACCESSORIES
